Moog type 2 oscillator module
Power supply: 29mA
Output waveform: sawtooth wave, square wave, triangle wave, sine wave, noise
OSC1 knob: Change the frequency of oscillator 1
OSC2 knob: Change the frequency of oscillator 2
RATE IN: Control the volume ratio of OSC1 and 2
V / oct ( 10bit, 5Vp-p)
Toggle the octave from -1 to +1 with the toggle switch.
RATE IN CV IN that controls the gain of OSC1 and OSC2.
DIY and docs: Github
Organise your case: ModularGrid
